Alloy 400 Bars, alloy 400 round bar, alloy 400 shafts, alloy 400 hex bars, ASTM B164 UNS N04400, Monel 400 bars, Monel 400 round bar, Monel bar, Monel 400 cold drawn bar, Monel 400 turned bar, Monel 400 polished bar, Monel 400 coil cold rolled, Monel 400 bar cold rolled, ASTM B164 Monel 400 Bars, Monel 400 Hex Bars, Monel 400 Forged Round Bars, Monel 400 Polish Bars, Monel 400 UNS N04400 Bars, Monel 400 DIN 2.4360 Bars , Monel Alloy JIS NW 4400 Bars, Monel 400 Polish Bars, Monel 400 Hex Bars Supplier and exporter in Mumbai, India.
Sagar Tubes (India) supplies a broad range of Monel 400 Bars according to ASTM B164, providing for requests of a wide scope of industries. Monel Alloy 400 Round Bars are available in Round, Hex and Flat structures. Alloy 400 Bars is proposed predominantly for use in high-temperature, seawater and acidic conditions.
Round bars are most as often as possible used to make parts, for example, gears, shafts, axles, and flywheels for rotating machinery applications. Round Bars can likewise be designed and utilized for manufacturing of seamless pipe and tubing utilized in oil drilling, military, and other applications. Monel 400 Round bars conform to ASTM, UNS, ASME, ANSI, EN standards and specifications. Round Bars are accessible in a wide range of sizes ranging from 10 mm to 125 mm. Monel Bar are accessible in following structures Round Bar, Hex Bars, Flat Bar, Square Bar. These Monel 400 Round bars are usually utilized in Engineering Construction, Residential Construction, Non-Residential Construction, Mining Infrastructure, Transport and Storage Manufacturing.
STI offers a far scope of Monel Bars which is accessible in Alloy and Stainless Steel grades. We pride ourselves on suppling Round Bar products to suit our customer’s accurate necessities. Our Round bars are manufactured according to En, BS, ANSI, ASME specifications. The length of the round bar is 50 mm to 6000 mm long and it very well can be Single Random, Double Random and Cut Length. The attributes of high resistance to thermal oxidation, corrosion resistance and high strength in our round bar meet the necessities for use in various applications inside the aviation, chemical processing, thermal processing, oil and gas, pharmaceutical and bio engineered and motorsport enterprises. We can supply ASTM B164 round bars with diameters between 0.5 mm to 500 mm.
| Specifications | : | ASTM B164 / ASTM SB164 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | : | 5 mm To 500 mm |
| Diameter | : | 0.1 mm to 100 mm |
| Length | : | 100 mm To 3000 mm Long & Above |
| Finish | : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Tolerance | : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Form | : | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
Types of Monel 400 Round Bars
| Monel 400 Bright Bar | : | Monel® 400 Bright Bar 400 Monel Bright Bar Monel Alloy 400 Bright Bar UNS N04400 Monel Bright Bar WERKSTOFF NR. 2.4360 Bright Bar ASTM B164 400 Monel Bright Bar |
| Monel 400 Hex Bar | : | Monel® 400 Hex Bar 400 Monel Hexagonal Bar 400 Monel Alloy Hex Bar UNS N04400 Monel Hexagonal Bar ASTM B164 400 Monel Hex Bar |
| Monel 400 Square Bar | : | Monel® 400 Square Bar 400 Monel Square Bars 400 Monel Alloy Square Bar UNS N04400 Monel Square Bar WERKSTOFF NR. 2.4360 Square Bar ASTM B164 400 Monel Square Bars |
| Monel 400 Rectangular Bar | : | Monel® 400 Rectangular Bar 400 Monel Rectangular Bars 400 Monel Alloy Rectangular Bar UNS N04400 Monel Rectangular Bars WERKSTOFF NR. 2.4360 Rectangular Bar ASTM B164 400 Monel Rectangular Bar |
| Monel 400 Flat Bars | : | Alloy 400 Flat Bar 400 Monel Alloy Flat Bars 400 Monel Flat Bars UNS N04400 Monel Flat Bars WERKSTOFF NR. 2.4360 Flat Bars ASTM B164 400 Monel Flat Bars |
| Monel 400 Polished Bar | : | Monel® 400 Polished Bar 400 Monel Polished Bars 400 Monel Alloy Polished Bar UNS N04400 Monel Polished Bars WERKSTOFF NR. 2.4360 Polished Bar ASTM B164 400 Monel Polished Bar |
| Monel 400 Threaded Bar | : | Alloy 400 Threaded Bar 400 Monel® Threaded Bars 400 Monel Alloy Threaded Bar UNS N04400 Monel Threaded Bar WERKSTOFF NR. 2.4360 Threaded Bar ASTM B164 400 Monel Threaded Bar |
Chemical Composition of Monel 400 Rond Bars:
| C | Mn | Si | Cu | Fe | Ni | S |
|---|---|---|---|---|---|---|
| 0.30 max | 2.00 max | 0.50 max | 28.00 – 34.00 | 2.50 max | 63.00 min | 0.024 max |
Mechanical Properties of Monel 400 Rond Bars:
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35000 , MPa – 240 | 0.4 |
