Alloy 25 copper rod, Beryllium copper C17200 bar, C17200 beryllium copper bars, BERYLLIUM COPPER ALLOY 25 round BARS AND BERYLLIUM COPPER ALLOY 25 WELDING RODS, UNS C17200/CDA 172 ROUND RODS, BERYLLIUM COPPER ALLOY 25 HEX BAR, C17200 beryllium copper rounds bars, Beryllium copper C17200 square bars, Alloy 25 copper threaded bars manufacturer, stockiest and supplier in Mumbai, India.
Sagar Tubes (India) is considered as one of the pioneers engaged with offering an enormous array of ALLOY 25 Round Bars. These bars are made of great quality steel material. Our C17200 Round Bars discover various applications in the development and construction business just as other business applications where quality reinforcement is vital and structures an imperative part of the development. Metal bars are utilized to make different items, for example, nuts, shafts etc.
C17200 Beryllium copper alloy bars is utilized in non-sparking safety tools, lock washers, navigational instruments, metal hoses, rolling plant parts, switch parts, pumps, spline shafts, substantial gear wear plates, roll pins, spring connectors, diaphragms, electro-chemicals, firing pins, washers, fuse clips, valve stems, and so forth. C17200 beryllium copper bar is being manufactured everywhere throughout the globe today, in order to provide in different enterprises, the necessary qualities of this material, which incorporate predominant thermal properties, hardness and high strength. It is this very scope of qualities of C17200 beryllium copper that make it the first choice material, for use in various applications in the aviation sector and oil industry.
One of the most noteworthy strength copper based alloys in the market is known as beryllium copper. There are a many business grades which contain 0.4 to 2.0 percent beryllium. Alloy 25 copper round bars is known to be utilized in a several applications, for example, oilfield tools, aviation landing gears, mechanical welding and many more. Beryllium copper C17200 bar combine high strength with non-magnetic and non-sparking qualities. It has amazing metalworking, forming and machining characteristics.
Alloy 25 rods and round bars are supplied in straight lengths up to 30 ft (9.1m). Solution annealed tempers are available in different diameters/thicknesses ranging from 0.030″ to 14″ (0.76 mm to 356 mm) and hard drawn tempers are available in 0.030″ to 3″ (0.76 mm to 76 mm). We specialize in 172 Beryllium, yet offer additional choice of beryllium copper bar in an assortment of extra specification and offer cut to length.
Beryllium Copper is an alloy that is machinable, ductile and weldable. Alloy 25 copper rod is exceptionally resistant to rough wear, plastic decomposition items, galling and to non-oxidizing acids such as carbonic acid and hydrochloric acid. Beryllium Copper C17200 bar is the strongest and the most broadly utilized of all the Beryllium Copper materials. Beryllium Copper C172 round bars comprises of 1.8 – 2% Beryllium. In Europe, Beryllium Copper C172 Bar is called as CuBe2 Bar. C17200 beryllium copper round bar is utilized in numerous application regions, for example, aviation bushings, drilling instrument components in the oil and gas industry, cores and cavities in injection mold tooling and bushings and plates in heavy equipment wear.
| Specifications | : | AMS 4650, AMS 4534, AMS 4651, AMS 4533, ASTM B196, MIL C 21657, SAE J463, SAE J461 |
| Dimensions | : | ASTM, ASME and AMS |
| Size | : | Custom Diameter & SIzes |
| Finish | : | Black, Bright & Polish |
| Length | : | Random, Fix & Cut Length |
| Form | : | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
Types of C17200 / Alloy 25 Beryllium Copper Bars
| C17200 / Alloy 25 Beryllium Copper Bright Bar | : | C17200 / Alloy 25 Beryllium Copper Bright Bar C17200 Copper Bright Bar Alloy 25 Beryllium Copper Bright Bar UNS C17200 Copper Bright Bar WERKSTOFF NR. 2.1247 Copper Bright Bar ASTM SB865 C17200 Copper Bright Bar |
| C17200 / Alloy 25 Beryllium Copper Hex Bar | : | C17200 / Alloy 25 Beryllium Copper Hex Bar C17200 Copper Hex Bar Alloy 25 Beryllium Copper Hex Bar UNS C17200 Copper Hex Bar WERKSTOFF NR. 2.1247 Copper Hex Bar ASTM SB865 C17200 Copper Hex Bar |
| C17200 / Alloy 25 Beryllium Copper Square Bar | : | C17200 / Alloy 25 Beryllium Copper Square Bar C17200 Copper Square Bar Alloy 25 Beryllium Copper Square Bar UNS C17200 Copper Square Bar WERKSTOFF NR. 2.1247 Copper Square Bar ASTM SB865 C17200 Copper Square Bar |
| C17200 / Alloy 25 Beryllium Copper Rectangular Bar | : | C17200 / Alloy 25 Beryllium Copper Rectangular Bar C17200 Copper Rectangular Bar Alloy 25 Beryllium Copper Bright Bar UNS C17200 Copper Rectangular Bar WERKSTOFF NR. 2.1247 Copper Rectangular Bar ASTM SB865 C17200 Copper Rectangular Bar |
| Titanium C17200 / Alloy 25 Beryllium Copper Flat Bars | : | C17200 / Alloy 25 Beryllium Copper Flat Bar C17200 Copper Flat Bar Alloy 25 Beryllium Copper Flat Bar UNS C17200 Copper Flat Bar WERKSTOFF NR. 2.1247 Copper Flat Bar ASTM SB865 C17200 Copper Flat Bar |
| C17200 / Alloy 25 Beryllium Copper Polished Bar | : | C17200 / Alloy 25 Beryllium Copper Polished Bar C17200 Copper Polished Bar Alloy 25 Beryllium Copper Polished Bar UNS C17200 Copper Polished Bar WERKSTOFF NR. 2.1247 Copper Polished Bar ASTM SB865 C17200 Copper Polished Bar |
| C17200 / Alloy 25 Beryllium Copper Threaded Bar | : | C17200 / Alloy 25 Beryllium Copper Threaded Bar C17200 Copper Threaded Bar Alloy 25 Beryllium Copper Threaded Bar UNS C17200 Copper Threaded Bar WERKSTOFF NR. 2.1247 Copper Threaded Bar ASTM SB865 C17200 Copper Threaded Bar |
Chemical Composition of C17200 / Alloy 25 Beryllium Copper Rods :
| Al | Be | Co | Cu | Si |
|---|---|---|---|---|
| 0.2 | 1.8 – 2.0 | 0.20 min | Rem | 0.2 |
Mechanical Properties of C17200 / Alloy 25 Beryllium Copper Rods:
| Tensile Strength (Min) | Yield Strength (0.2%Offset) Min | Elongation %(Min) | Hardness HRC (Min) |
|---|---|---|---|
| 1050 | 850 | 2 | 35 |
