EN-19 Plates, EN19 Sheet, SAE 4140 Plates, 42CrMo4 Steel Plate, SCM440 Plate, EN19 Alloy Steel Sheet, EN-19 Alloy Steel Plate, EN19 Sail Hard Steel Plate Suppliers & Exporters in Mumbai, India.
Sagar Tubes (India) is one of the prominent manufacturer, stockiest and supplier of EN-19 Plates. EN-19 Plate is a good quality Quenched and Tempered Alloy Structural Steel. Good ductility is an aftereffect of high quality steel, high tensile strength and shock resisting properties in combination with resistance to wear. EN-19 Steel Plate is likewise known as AMERICAN SAE 4140 Plate. EN-19 sheet is a top notch quality alloy steel with tensile strength. It is a higher quality medium carbon. EN-19 Steel Plate is one alloy steel grade in BS 970-1955 standard, which is determination for wrought steels for mechanical and allied engineering purposes.
With a combination of great ductility and the shock resistance, EN-19 Plate is appropriate for applications with extremely high loading, for example, engine gear boxes. SAE 4140 Plates are a prevalent material in the automotive sector it is conceivable to machine the material extremely accurately. EN-19 Plate Alloy is moreover in demand by Oil industry & Gas industry. 42CrMo4 Steel Plate is a prime preference due to its high strength. The SCM440 Plate equivalent grades are DIN 1.7225/42crmo4 sheet, AISI 4140 sheet.
AISI 4140 steel plate is an engineering alloy steel having chromium and molybdenum. EN-19 Alloy Steel Plate comes under the clasification of low alloy steel. EN-19 Plates have high fatigue strength, toughness, abrasion and impact resistance, and torsional strength. EN-19 Alloy Steel Sheet can be heat treated in a numerous ways to provide it a combination of properties. Oil Quenched and Tempered Hardness is 28-34 HRc. EN-19 Sheets Annealing delivery hardness is under 250HB. EN-19 Sail Hard Steel Plate have higher tensile strength of 850- 1000 Mpa.
You can get the exact material according to your requirement at the least possible price. We also provide Reworks, FOB, CFR, CIF, and door to door delivery prices. The materials we offer are completely verifiable, right from raw material test certificate to the final dimensional statement. E-guarantee to give a response within 24hours working hours (usually in the same hour).You can also get stock alternatives, mill deliveries with minimizing manufacturing time. We are completely dedicated to our customers. If it will not possible to meet the customer requirements after examining all options, we will not mislead by making false promises which will create good customer relations.
Exporter of EN19 sheets, EN-19 Plates, SCM440 Plates, SAE 4140 Plate in India,42CrMo4 Steel Plates, EN-19 Alloy Steel Plates, EN19 Alloy Steel Sheets, EN19 sailhard steel plate price in India, EN19 steel plate , 42CrMo4 Steel Plate,AISI 4140 steel plate,EN19 sailhard steel plate.
| Thickness | : | 2-300mm |
| Width | : | 600-25000mm |
| Length | : | 600-12000mm |
| Wall Thickness | : | 0.2-400mm |
| Surface | : | Black Painting, Varnish Paint, Anti Rust Oil, HOt Galvanized, Cold Galvanized, 3PE. |
Types of EN-19 Plates
| EN-19 Polished Plates | : | EN-19 Polished Plates EN-19 Carbon Steel Polished Plates EN-19 Carbon Steel Class 1 Polished Plates EN 1.7225 Polished Plates |
| EN-19 Hot Rolled Plates | : | EN-19 Hot Rolled Plates EN-19 Carbon Steel Hot Rolled Plates EN-19 Carbon Steel Class 1 Hot Rolled Plates EN 1.7225 Hot Rolled Plates |
| EN-19 Cold Rolled Plates | : | EN-19 Cold Rolled Plates EN-19 Carbon Steel Cold Rolled Plates EN-19 Carbon Steel Class 1 Cold Rolled Plates EN 1.7225 Cold Rolled Plates |
| EN-19 Coils | : | EN-19 Coils EN-19 Carbon Steel Coils EN-19 Carbon Steel Class 1 Coils EN 1.7225 Coils |
| EN-19 Strips | : | EN-19 Strips EN-19 Carbon Steel Strips EN-19 Carbon Steel Class 1 Strips EN 1.7225 Strips |
| EN-19 Foils | : | EN-19 Polished Foils EN-19 Carbon Steel Foils EN-19 Carbon Steel Class 1 Foils EN 1.7225 Foils |
| EN-19 Shim Sheets | : | EN-19 Shim Sheets EN-19 Carbon Steel Shim Sheets EN-19 Carbon Steel Class 1 Shim Sheets EN 1.7225 Shim Sheets |
| EN-19 Chequered Plates | : | EN-19 Chequered Plates EN-19 Carbon Steel Chequered Plates EN-19 Carbon Steel Class 1 Chequered Plates EN 1.7225 Chequered Plates |
| EN-19 Perforated Sheet | : | EN-19 Perforated Plates EN-19 Carbon Steel Perforated Plates EN-19 Carbon Steel Class 1 Perforated Plates EN 1.7225 Perforated Plates |
| EN-19 Circle | : | EN-19 Circle EN-19 Carbon Steel Circle EN-19 Carbon Steel Class 1 Circle EN 1.7225 Circle |
Chemical Composition of EN-19 Plates:
| C | Mn | Si | Ni | Mo | Cr | P | S |
|---|---|---|---|---|---|---|---|
| 0.35-0.45 | 0.5-0.8 | 0.1-0.35 | – | 0.2-0.4 | 0.9-1.5 | 0.05 max | 0.05 max |
Mechanical Properties of EN-19 Plates:
| Heat Treatment | Tensile Strength Rm N/mm² | Yield Stress Re N/mm² | a% on 5.665ÖSo | Impact Izod J | Impact KCV J | Proof Stress rp0.2 | Hardness HB | Size mm |
|---|---|---|---|---|---|---|---|---|
| R | 700/850 | 495 | 15 | 34 | 28 | 480 | 201/225 | >100≤250 |
| S | 775/925 | 555 | 13 | 27 | 22 | 540 | 223/277 | >150≤250 |
| S | 775/925 | 585 | 15 | 54 | 50 | 570 | 223/277 | >63≤150 |
| T | 850/1000 | 680 | 13 | 54 | 50 | 655 | 248/302 | >29≤100 |
| U | 925/1075 | 755 | 12 | 47 | 42 | 740 | 269/331 | >13≤63 |
| V | 1000/1150 | 850 | 12 | 47 | 42 | 835 | 293/352 | >6≤29 |
| W | 1075/1225 | 940 | 12 | 40 | 35 | 925 | 311/375 | >6≤19 |
